Audient ASP510

Stereo and Surround Sound Monitor Controller

• The Audient ASP510 can be easily integrated into any analogue or workstation-based surround setup and provides comprehensive control of monitoring and recording functions for a wide range of surround formats, including 5.1
• LCRS
• Dolby
• DVD video
• DVD audio
• DTS and SACD. This makes the ASP510 the perfect solution for a wide range of applications, such as surround music production
• DVD/SACD/DTS authoring, post-production, film production, video game production, digital television
• AV production and multi-channel OB vans., supports three 5.1 surround and three stereo sources
• 6 preset monitor formats
• 8 inputs for consoles or DAW (5.1 surround plus stereo)
• 8 outputs for recorders (5.1 surround plus stereo)
• Switchable encoder/decoder insertion
• 6 tunable speaker outputs
• Individual speaker cut/isolate functions
• Universal solo and monitor system interface
• Customisable reference and dim monitoring levels
• Frequency response: 22-22 Hz
• Pink Noise Generator
• Input for Guide Track
• Ergonomic control panel
• 120 Hz Subbass Filter
• 25pin D-type females für: 5.1 Surround Wiedergabe A und B
• 5.1 Surround Bus inputs
• 25-pin D-type males for: 5.1 surround recording A and B
• Speaker outputs
• Encoder
• 1 U
• 19" (ASP510)
• Remote control dimensions: 230 x 120 x 40 mm
• Weight: 5000 g
