LightShark LS-1

Light Control Panel

• Hybrid web browser based lighting control console
• The independent light console can be controlled via web browser via any tablet, smartphone or PC
• 4 Encoder wheels
• 10 Playback faders
• Grand Master fader
• Colour display and function keys
• Easy-to-use and intuitive user interface with Multi-Touch function
• Internal web server with wireless access point
• Supports DMX
• ArtNet
• ACN
• MIDI
• UDP
• OSC and HTTP
• Built-in effects generator with modifiable effects
• Adjustable FX size and speed
• Fanning
• Unlimited number of user presets
• User definable Executor window
• Manual crossfade for theatre applications
• Up to 4 DMX lines via ArtNet / Up to 8 DMX lines via sACN E1.3.1
• Extensive device library and internal fixture editor
• Up to 1200 cues
• Up to 30 virtual playbacks
• RGB & CMY colour picker
• Included power cord
• Suitable case: Art. #500973# (not included),

Note: Tablet not included, *Technical data*, 2 DMX outputs each XLR 5pin and 3pin, Network output, 2x USB, Power input via Power Twist TR1, Connection for desk lamp: XLR 3pin, 5 V, Internal power supply, Power supply: 90 - 250 V at 50/60 Hz, Power consumption: 1.1 A at 230V, Dimensions: 430 x 334 x 94 mm, Weight. 3.6 kg
