Telycam Explore SE Wh

4K PTZ Camera

• Equipped with fast PDAF autofocus
• 30x optical zoom and versatile connection options such as NDI
• NDI HX
• 12G-SDI
• 3G-SDI
• HDMI
• USB and SFP+
• Genlock for synchronisation in multi-camera productions
• FreeD Integration for Virtual Productions
• Audio with 3.5 mm line-in and mini XLR with phantom splicing
• SSDP for convenient network setup
• Local backup via microSD card
• Dual tally light on the front and back for quick identification from all sides
• CROP output: supports different image sections in parallel (e.g. long shot and close-up)
• Auto-Tracking
• Input voltage: DC12V
• POE++ (IEEE802.3bt)
• Tolerated temperature range during operation: -10 °C ~ 50 °C
• Tolerated humidity during operation: =50 dB, *Image parameters:*
• Noise reduction: 2D & 3D
• Minimum illumination: 0.5 lux (50 IRE Max AGC
• 1/30
• F1.8)
• White balance: Auto / Manual / ATW / Push / Indoor / Outdoor / Colour Temperature
• Exposure: Auto / Manual / Aperture priority / Aperture priority / Brightness priority
• Anti-Flicker: OFF / 50Hz / 60Hz
• Image Flip / Mirroring: supported
• Focus / Iris / Electronic shutter: Auto / Manual
• Gamma: supported
• Backlight compensation: supported, *Video formats:*
• 12G-SDI: 3840 * 2160 P60/50/30/25/59.94/29.97/24/23.98
• 1920 * 1080 P60/50/30/25/59.94/29.97/24/23.98
• 1920 * 1080 I60/50/59.94
• 1280 * 720 P60/50/30/25/59.94/29.97
• 3G-SDI: 1920 * 1080 P60/59.94/50/30/29.97/25/24/23.98
• 1920 * 1080 I60/59.94/50
• 1280 * 720 P60/59.94/50/30/29.97/25
• HDMI2.0: 3840 * 2160 P60/50/30/25/59.94/29.97/24/23.98
• 1920 * 1080 P60/50/30/25/59.94/29.97/24/23.98
• 1920 * 1080 I60/50/59.94
• 1280 * 720 P60/50/30/25/59.94/29.97
• NDI HX3: Main Stream: 3840 * 2160 P15 ~ 60
• 1920 * 1080 P15~60
• 1280 * 720 P15~60
• 1024 * 576 P15~60
• Sub Stream: 640 * 360 P15~30
• SFP+: 3840 * 2160 P60/50/30/25/59.94/29.97/24/23.98
• 1920 * 1080 P60/50/30/25/59.94/29.97/24/23.98
• 1920 * 1080 I60/50/59.94
• 1280 * 720 P60/50/30/25/59.94/29.9
• USB Type-C: NV12: 1920 * 1080 P5
• 1280 * 720 P15
• 1024 * 576 P25
• 800 * 448 P30
• YUYV: 1920 * 1080 P5
• 1280 * 720 P15
• 1024 * 576 P25
• 800 * 448 P30
• MJPG: 3840 * 2160 P30
• 1920 * 1080 P60
• 1280 *720 P60
• 1024 * 576 P60
• 800 * 448 P60
• H264/H265: 3840 * 2160 P30
• 1920 * 1080 P60
• 1280 * 720 P60
• 1024 * 576 P60
• 800 * 448 P60, *IP streaming:*
• Video encoding: H.264/H.265
• Bitrate Control: Variable bitrate (VBR) / Constant bitrate (CBR)
• Bitrate Range: 1024 Kbps ~ 122800 Kbps
• Network Port Speed: 1000M
• Protocols: NDI,NDI HX3
• SRT
• HTTP
• RTSP
• RTMP
• ONVIF
• VISCA over IP(TCP&UDP)
• VISCA
• PELCO P/D
• SSDP
• FreeD
• NTP
• RTP Multicast
• WebRTC, *Pan/Tilt movement:*
• Preset: Remote controller: 10
• Serial port: 256
• Accuracy: 0.1°
• Pan rotation range: -176° ~ +176°
• Tilt rotation range: -90° ~ +90°
• Pan rotation speed: 0.1° ~ 80°/s
• Tilt rotation speed: 0.1° ~ 60°/s, *I/O interface:*
• Control Port: RS232
• RS485
• RS422
• RJ45
• USB
• NDI HX
• Video Port: NDI
• NDI HX3
• HDMI 2.0
• 12G-SDI
• 3G-SDI
• SFP+
• USB Type-C
• Audio port: Mini XLR (with phantom splicing)
• Stereo 3.5 mm Line in
• Tally: supported
• POE++: supported
• Daisy chain: supported
