Kramer 690R SDI Receiver

High-performance Receiver

• For 3G HD-SDI signals via fibre optic cable
• The 690T transmitter (not included) converts two 3G HD-SDI signals into a single mode fibre optic signal and the 690R receiver converts this back into the two original SDI formats
• Compatible with the VS-88FO fibre optic matrix
• HDTV compatible
• Multi-standard operation: SDI (SMPTE 259M and SMPTE 344M)
• HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M)
• Compliant laser standards: IEC 60825-1
• FDA 21CFR1040
• Laser class 1
• Equalisation and re-clocking technology: Reconstructs the digital signal to bridge greater distances with coax cable: 200 m (HD-SDI) or 100 m (3G HD-SDI)
• Includes power supply unit, *Technical specifications:*
• Inputs: 2x single mode (9/125) with LC socket
• Outputs: 2x SD/HD/3G HD-SDI with BNC socket
• Bandwidth: 3 GBit/s per input
• Fibre optic range: 10 km for 3G HD-SDI
• Power supply: 5 V DC
• 480 mA
• Weight: 0.1 kg
• Dimensions: 6.22 x 5.18 x 2.44 cm
